TEOSAW APEX X5 X6 X7 225mm 275mm 315mm Wheelbase 5 6 7 Inch Frame Kit Compatible

(5.00) 1 Reviews 0 Wish listed

AED98.29

Quantity :

Total price :

(Tax : )

Product Reviews

Ayser Sabri

Love this 3 inch frame only complaint is the rubber inserts that the camera mount to for dampening are too soft so you get jello effect at high throttle. To fix this I put washers between the camera screws and the inserts and it removes the jello effect completely.

Product Overview

Specifications:

Brand: TEOSAW Model: APEX X5/X6/X7
Item Name: 5 Inch/6 Inch/7 Inch Frame Kit

Model:

APEX X5

APEX X6

APEX X7

Wheelbase:

225mm

275mm

315mm

Appearance Size:

Approx.165mm x 213mm x 35mm

Approx.189mm x 253mm x 35mm

Approx.212mm x 286mm x 35mm

Weight:

Approx.134g

Approx.143g

Approx.151g

Structure:

X-type split

Thickness:

Arm 5.5mm, bottom plate 2.5mm, splint 2.5mm, upper plate 2.0mm, side plate 2.0mm

Applicable Propeller Size:

5-5.1 Inch

6 Inch

7 Inch

FC Mounting Hole:

20*20mm（M3），30.5*30.5mm（M3）

VTX Mounting Hole:

20*20mm（M2），25.5*25.5mm（M2）

Camera Installation Width:

20mm/19mm

Internal Height:

Approx.20-28mm

Motor Mounting Hole:

16*16mm（M3），19mm*19mm（M3）

Compatible VTX:

DJI O3 Air Unit/VISTA Sky Unit/Analog, etc.

Sheet Material:

3K（T700）

Remarks

Features:

1. Versatile Prop Compatibility: Supports prop sizes of 5-5.1 inch (X5), 6 inch (X6), and 7 inch (X7), catering to various racing needs and preferences.

2. Optimized Weight Distribution: With weights of 134g (X5), 143g (X6), and 151g (X7), the frames ensure optimal balance and handling during high-speed flights.

3. Integrated Camera Mounts: Features versatile camera installation depths of 20mm/19mm, supporting different camera setups for enhanced FPV experiences.

4. Easy Assembly and Maintenance: Pre-drilled holes for flight controllers and motor mounts ease the assembly process, ensuring quick setup and easy maintenance

Package included:

1x APEX X5/APEX X6/APEX X7 Frame
