Product Overview

ice:
1. It is Empty Frame Kit, not include FC,ESC, Motor, Propeller, VTX, Camera, Battery, etc.
2. It Comes unassembled. Need build by buyers.


Specifications:

Brand: TEOSAW Model: APEX DC5/DC7

Item Name: 5 Inch/7 Inch Frame Kit

Model:

APEX DC5

APEX DC7

Wheelbase:

245mm

340mm

Appearance Size:

187mm x 230mm x 35mm

222mm x 309mm x 35mm

Weight:

Approx.138g

Approx.170g

Structure:

DC Structure

Thickness:

Arm 5.5mm, Bottom Plate 2.5mm, Splint 2.5mm, Upper Plate 2.0mm, Side Plate 2.0mm

Applicable Propeller Size:

5-5.1 inch

7 inch

Flight Controller Mounting Hole:

20*20mm(M3),30.5*30.5mm(M3)

VTX Mounting Hole:

20*20mm(M2),25.5*25.5mm(M2)

Camera Installation Width:

20mm/19mm

Internal Height:

20-28mm

Motor Installation Mounting Hole:

16*16mm(M3),19mm*19mm(M3)

Compatible VTX:

DJI O3 Air Unit/VISTA Sky Unit/Analog, etc.

Sheet Material:

3K(T700)





Feature:

1. Lightweight and Portable: Weighing approximately 138g/170g, the DC5/DC7 drone frame is incredibly lightweight, enabling easy portability and efficient flights.

2. Versatile Camera Mount: Equipped with a 20mm/19mm camera mount, providing versatility for different camera setups and optimal viewing angles.

3. Easy Installation: Features multiple mounting holes and an internal height of 20-28mm, allowing easy installation of various electronics and flight controllers.

4. Perfect Compatibility: Compatible with DJI O3 Air Unit and VISTA, designed to fit motors ranging from 5-7 inches, ensuring seamless integration with popular drone components

Package included:

1x APEX DC5/APEX DC7 Frame
